Pipe Laser Cutting Machine With Automatic Loading And Unloading

Pipe Laser Cutting Machine With Automatic Loading and Unloading

Product Details






Technical Parameter

Part Name & Descriptions

remark

 Laser

1000WRaycus(China Brand             1000W   IPGGerman Brand

Optional

Optical system

Import Media diaphragm

UK

Laser cutting head

Quelle(without Auto   focus)

Autofocus   optional

China

Reducer

Shimpo

Japan

Water chiller

Over-flow protection,             temperature stability ± 0.5

Wuhan, China

Rack&Pinion

Bevel type : ROR or   Atlanta

German

Guide Rail

Hiwin Or PMI

Taiwan

Button Module

Schneider

German

AC Contactor

Schneider

German

Solenoid Valve

Airtec

Taiwan

High precision   auto-sensor

Accuracy ±0.1mm

China

PC System

Industrial control

EVOC, Taiwan

X axis servo

750W Bus Servo

Panasonic, Japan

Y axis servo

4000W Bus Servo

Panasonic, Japan

Z axis servo

750W Bus Servo

Panasonic, Japan

W axis servo

1000W for back chuck(Pneumatic)

5000W for front chuck(Pneumatic)

Panasonic, Japan

Proportional Valve

SMC(for O2)

Japan

Control system

Tubepro

Friendess,China

PC

Cyptronic, Bus   CNC

Friendess,China

I/O Card

136 points

China

Table

Strictly make table with   hardening, tempering and anealing treatment to ensure no deformation during   long time production

QY, China

Laser Source

IPG: 500W-2000W

Raycus:500W-2000W

Mechanical   Parameter

Pipe Area

Round Pipe:   20-200mm                                      Square Pipe: 20-140mm

Pipe Length

6000mm

Max Loading   Weight

3T

X Stroke

170mm

Y Stroke

6980mm

Z Stroke

260mm

W Stroke

Rotation   Axis                                                   high precision rack transimission)

Pipe Loading   Time

first pipe 60s   for round pipe

from 2nd pipe   continued loading within 30s

Y Axis Moving   Speed

0.8m/s(48m/min)

Max Chuck   Rotation Speed

120rpm

Max Cutting   Rotation Speed

100rpm

Continuous   Cutting Tailings

250mm

Min.Tailings

80mm

Cutting Table   Mechanical Accuracy

±0.08mm

XYZ Positioning   Accuracy

±0.05mm/m

XYZ Repeat   Positioning Accuracy

±0.05mm

Max Single Pipe   Loading Weight

290kg

Unloading

Two Parts, for   small pipe and long cutting

Side Door

Moving height can be adjusted   automatically

Layout(L*W*H)

12100mm×4950mm×2850mm

Power   Parameter

Phase

3

Rated Voltage

380V

Frequency

50Hz

Power   Consumption

30KW

Total Power   Protection Level

IP54
