1530 2000W Fiber Laser Cutting Machine

We supply 1530 2000W Fiber Laser Cutting Machine. Features:Low running cost Low energy consumption Low maintenance cost High performance High speed High quality High accuracy High efficiency Application： High power fiber Laser cutting machine is widely used in processing of carbon steel, stainless still, alloy steel, galvanized sheet,...

Send Inquiry Chat Now

Product Introduction

Features：

●Hydraulic adjustment of high and low double exchange table, saving loading and unloading time.

●The widened guide rail support surface further optimizes the rigidity of the bed.

●The composite heat-insulating armor effectively protects the structural stability of the main beam of the bed under the environment of ultra-high-power laser processing.

●Fully enclosed housing structure with high safety.

●Energy saving and environmental protection, perfect smoke and dust removal system.

Technical Parameter:
Item	Parameter	2000W
1	Laser Generator	IPG German, or Raycus made in China
2	Laser Wavelength	1070nm
3	Laser Repeat Frequency	CW
4	Mechanical driving system	Rack&Pinion, ATLANTA, German
5	PC System	Industrial control,EVOC, Taiwan
6	X axis servo unit	1000W servo single driving, Fuji, Japan
7	Y axis servo unit	2000W servo dualdriving, Fuji, Japan
8	Z axis servo unit	400W servo single driving, Fuji, Japan
9	Limit switches	NPN,Omron,Japan
10	Min Linewidth	0.15mm
11	Max.Cutting Thickness	≤18mm for carbon steel ≤8mm for stainless steel
12	Continued Working Time	≥20 hours
13	Max.Cutting Dimension	150*300cm
		150*600cm
		200*600cm
14	Wortable Cutting Accuracy	0.05mm/m
15	Repeated Positioning Precision	±0.05mm/m
16	Power Supply	Three-phase 5 wires AC 380V±5%，50Hz±1%
