Super Large Format Fiber Laser Cutting Machine For Steel Metal

Super large format fiber laser cutting machine for steel metal

Features:

Humanized design, more practical user experience;

The flexible motion control system makes cutting easier;

Germany ROR rack and pinion, Taiwan PMI and other brands guide rail, Huichuan motor, higher stability.

Applied material:

Professional for cutting 0.5mm-50mm carbon steel plate, 0.5mm-50mm stainless steel plate, galvanized plate, electrolytic plate, silicon plate, 0.5mm-6mm aluminum alloy, 0.5mm-4mm brass and other metal materials (thickness and material related to laser)

Technical parameter:

Max Cutting Speed	140m/min	Laser Power	12000W-30000W
Max Acceleration	1.4G	Power Consumption	6KW-15KW
X/Y Positioning Accuracy	±0.03mm/m	Machine Running Temperature	0℃-40℃
X/Y Repeated Positioning Accuracy	±0.02mm	Machine Running Humidity	﹤90%
Operating Voltage	380V/50Hz	Transmission	Precise rack and pinion

High rigidity machine tool

Bed part:
The bed has a smoking port, through the smoke exhaust pipe for automatic smoking, can make the smoke generated in the cutting process easily discharged outdoors, improve the working environment.

Beam section:
Using gantry beam design, light weight, good rigidity, good dynamic performance, smooth operation. The use of fully enclosed dust-proof structure, so that the internal gear rack, linear guide rail service life greatly improved.



Qingyuan Laser is well-known as one of the largest and professional super large format fiber laser cutting machine for steel metal manufacturers and suppliers in China. With a group of professional and effective personnel, we can offer you super large format fiber laser cutting machine for steel metal at low price.
