3 Chuck Zero Tailing Wastage Stainless Steel Aluminum Carbon Steel Metal Pipe Laser Cutting Machine With Bevel Cutting

Qingyuan Laser is well-known as one of the largest and professional 3 chuck zero tailing wastage stainless steel aluminum carbon steel metal pipe laser cutting machine with bevel cutting manufacturers and suppliers in China. With a group of professional and effective personnel, we can offer you 3 chuck zero tailing wastage stainless steel aluminum carbon steel metal pipe laser cutting machine with bevel cutting at low price.



3 Chuck Zero Tailing Wastage Stainless Steel Aluminum Carbon Steel Metal Pipe Laser Cutting Machine with Bevel Cutting

Technical Parameter

Model	0160；0260；0360	Max Cutting Speed	100m/min
X/Y Positioning Accuracy	±0.03mm	Max Rotating Speed	100rpm
X/Y Positioning Repeated Accuracy	±0.05mm	Max Acceleration	1.2G
Pipe Cutting Accuracy	±0.3mm	Power Consumption	23.5kW
Operating Voltage	380V/50Hz	Machine Running Temperature	0℃-40℃
Machine Dimension(mm)	16000x4400x2800；17000*4700*3000	Machine Running Humidity	<90℃
Laser Power	1500w-3000w	Pipe Diameter(mm)	Round tube 20-240 Square tube 20-160

Features:
●The card has the center function of self -regulation, which can realize the fast -molecut folder.
●Automatic finding function.
●Segmental delivery cutting to improve cutting accuracy.
●With the dual -clip -holding function of the intermediate mount, the three -card structure can assist the correction of the deformation of the small pipe and improve the cutting accuracy.
●It can achieve zero -tail cutting and improve material utilization.
●High -speed automatic cutting, satisfying the cutting of different types of tubes such as round tube, square tube, rectangular tube.

Application Material:It is used to cut a 1-10mm round tube, square tube, rectangular tube and other alien metal pipes. It can be suitable for round pipe φ20mm-φ240mm.

Series Products

Model	0160	0260	0360
Pipe Length(mm)	6000	6000	6000
Exterior Dimensions(mm)	16000*4400*2800	16000*4400*2800	17000*4700*3000
Tube Diameter(mm)	Round tube Φ20-Φ160	Round tube Φ20-Φ240	Round tube Φ20-Φ350

Company Overview



QY laser was established in 2008, dedicated to fiber laser cutting machine technology, design, production and sales. We pay attention to the technology, the quality, the application, the market optimization conformity and take "higher efficiency, higher performance, higher precision" as our goal. We are committed to fiber laser cutting machines from 1500 watts to 40,000 watts and we have developed more than 90 products, each machine has reached an excellent level in domestic and foreign markets.

Standardized production plant

Package and Delivery

Comopany Advantages

1.The first batch of manufacturers of fiber laser cutting machine We are one of the first manufacturers of fiber laser cutting machine in China, and we have a deep technical background.

2.Leading technology, constantly leading the industry's new applications, a number of domestic first first set of products.

3.Nearly 20 years of experience in the laser industry, the team has a strong accumulation of technology.

4.Our products have passed the U.S. FDA, European CE certification, with nearly one hundred patent certificates.

5.Reliable quality, exquisite craftsmanship, perfect after-sales service.

6.High degree of product autonomy: The main control spare parts have all been completed independent, more than 90% of the components have been localized, the quality meets or even exceeds the international standards, and the after-sales service is quick.

If you are interested in our products,welcome to contact us:

Webisite: www.qy-lasers.com;

Mail: ivy.liu@qy-laser.com;

Wechat/Whatsapp: 0086 15895446133
