How To Debug The Laser Cutting Machine?

How to debug the laser cutting machine to make the best use of it? In fact, machines, like people, need frequent maintenance. Only in this way can the equipment be kept in a better running state. There are many parts in laser cutting equipment, and the maintenance cycle of some parts is relatively short. So you always need someone to maintain it.

1.Adjust the machine assembly to improve the cutting effect of the machine.
① Installation of guide rails:
When installing the rail, keep the guide rail parallel. When laser equipment leaves the factory, it needs to be repeatedly debugged to ensure the cutting effect of each device from the factory. If the guide rail is not parallel, there will be resistance when the machine is running. Most of the incisions will have jagged edges, so the Y -axis rail needs to be kept parallel.
②The installation location of the beams and axis is not good:
During the installation of the beam and a shaft, if there is no lock screw or the tightness and loosening, it will affect the cutting effect of the laser cutting machine.
2. Adjust the parameters of the laser machine and improve the cutting speed of the machine.
The machine tool parameter settings need to be gradually adjusted during the cutting process. Generally speaking, if the machine is not adjusted properly, the cutting speed will be affected, either speed or effect. It is our responsibility to reach a state of existing speed and effect. Debug need to be debugged according to the material of the customer. At the factory, each parameter of the laser cutting machine is set, but the later period can be adjusted according to the user's needs. Generally, when setting parameters, pay attention to the following points:.
①Initial speed:
As the name suggests, this setting is the speed of the machine start. First of all, the initial speed is not as fast as possible. In fact, if the speed is too fast, the machine may shake very well at the beginning.
②Acceleration:
Acceleration is a acceleration process from initial speed to normal cutting when the machine is produced. Similarly, when the machine is prepared to end the cutting, there will be a deceleration process. If the acceleration is too low, the cutting speed of the machine will change.
3. Debugging method of laser cutting machine accuracy
①When the light spots that focus on the laser are adjusted to the lowest hour, the effect of the light spots is created by the light spots, and the focus position is determined by the size of the light spots effect. We only need to confirm that the laser spots are at the minimum value, so this position is the focus of processing, so that we can start processing.
②In the first part of the laser cutting machine debugging, we can use some debug paper and workpiece waste to determine the accuracy of the focal length position through point shooting, and move the height of the upper and lower laser heads. Essence Adjust different positions many times, and find the minimum spot position to determine the focal length and appropriate position of the laser head. The workpiece processing of laser cutting machines has no burrs, wrinkles, high accuracy, and is better than plasma cutting. For many machinery and electrical manufacturing industries, because the CNC laser cutting system can easily cut different shapes and sizes of workpieces, it is often more popular than stamping and molding processes. It does not need to repair the mold, but also saves the time to replace the mold, which saves processing costs and reduced product costs.
