High Power High Quality Cnc Metal Fiber Laser Cutting Machine

It is professionally used for cutting round pipes, square pipes, rectangular pipes and other heterogeneous metal pipes with a thickness of 1-10mm. It is suitable for round pipes with a diameter of 20-219mm, a square pipe with a side length of 20-150mm, and a maximum pipe length of 6000mm.

Send Inquiry Chat Now

Download

Product Introduction

High Power High Quality Cnc Metal Fiber Laser Cutting Machine

3 chuck zero tailing wastage pipe laser cutting machine

Features

● The spindle has a central self-regulation function;

● With automatic center search function;

● Segmented feed cutting to improve cutting accuracy;

● The three spindle structure and the double spindle function of the middle spindle can help correct the deformation of the small tube and improve the cutting accuracy;

● No waste, high material processing speed;

● Automatic cutting at high speed.

Parameters

Items	Main parts	Brand	Original
1	2000W Laser Generator	IPG	German Brand
1	2000W Laser Generator	Raycus	China Brand
2	Lubrication system	QY	China
3	Laser cutting head	Raytools (AUTO FOCUS)	Switzerland
4	Reducer(Gear box)	Shimpo	Japan
5	Water chiller	Hanli	China
6	Rack and Pinion	ROR	German
7	Guild Rail-X/Y axis	PMI linear guide rail	Taiwan
8	Solenoid Valve	Airtac	Taiwan
9	Proportional valve for O2	SMC	Japan
10	High precision following	BSC100	China
11	Industry PC	Nodka	China
12	X axis servo and Motor	Yaskawa/Panasonic	Japan
13	Y axis servo and Motor
14	Z axis servo and Motor
15	Control System	English language	Friendess, China
16	Nesting software	Nest-drawing processing, nesting, tool path generation and remote task transmission etc.	Friendess, China
17	Electrical components	Schneider	France
18	Table Production	10mm steel plate welding	QY, China
		Anti-rust paint treatment
		Annealing-remove stress
		Milling machine processing -ensure the accuracy of guide rail
		Painting
		Testing by API LASER interferometer, to ensure the accuracy

▲Applicable materials: cutting round pipes, square pipes, rectangular pipes and other heterogeneous metal pipes with a thickness of 1-10mm. It is suitable for round pipes with a diameter of 20-219mm, a square pipe with a side length of 20-150mm, and a maximum pipe length of 6000mm.
